Peel

Check the bottle, the imprint, and the pill — then read the evidence.

Peel is an open-source medicine check for places where a tablet and its packaging may not match. Photograph the bottle, read the imprint, measure the pill. The backend turns those three observations into a sourced report against a regulatory corpus, live web evidence, and (when present) a hardware reading.

Watch the Peel app demo

Table of contents

• Why Peel exists
• Architecture
• Backend
• Getting started
• HTTP API
• Peel Voice Agent
• Project layout
• License

Why Peel exists

People often cannot tell whether the tablet in their hand is the medicine on the label. Packaging can be copied. Imprints can be faked. The contents are the part you cannot see.

Peel keeps three observations separate, then looks them up:

Observation	Source
Bottle	GPT-4o vision reads a photo of the container (name, strength, NDC, lot, manufacturer).
Imprint	GPT-4o vision reads a photo of the tablet (characters, color, shape).
Pill	A phone-attached instrument records optical sensor data; POST /scans carries the actual readings to research and voice.

The rest of this README is the system that sits behind those three inputs.

Architecture

flowchart TB
  subgraph clients [Clients]
    phone[Phone / Flutter]
    hw[XIAO + BOX-3 instrument]
  end

  subgraph runpod [Runpod — FastAPI]
    vision[GPT-4o vision]
    scans[POST /scans]
    pipe[Research pipeline]
    voice[Deepgram session]
  end

  subgraph elastic [Elastic Cloud Serverless]
    reg[peel-regulatory]
    pills[peel-pills]
    ndc[peel-ndc]
    web[peel-web-pages]
    history[peel-scans]
    kibana[Kibana Agent Builder]
  end

  subgraph live [Live web]
    fc[Firecrawl]
  end

  phone -->|bottle + imprint photos| vision
  hw -->|USB serial JSON| phone
  vision --> scans
  phone -->|hardware observation| scans
  scans --> pipe
  pipe -->|exact + hybrid search| reg
  pipe --> pills
  pipe --> ndc
  pipe --> history
  pipe -->|stage 3 search / scrape| fc
  fc -->|index pages| web
  pipe -->|stage 4 ESQL tools| kibana
  kibana --> reg
  kibana --> pills
  kibana --> ndc
  kibana --> web
  kibana --> history
  pipe -->|scan_context| voice

Loading

A check is one scan document in Elasticsearch. The phone (or curl) posts bottle, imprint, and hardware observations to POST /scans. That returns 202 immediately with status: pending. A background asyncio task then researches the scan and writes back to the same document. The client polls GET /scans/{id}.

pending  →  partial  →  complete
              ↑             ↑
         ~0.3–3 s        ~25–60 s
      exact lookups    agent + coerce

Status	Meaning
pending	Scan exists; research is still starting.
partial	Deterministic Elasticsearch lookups are done. The report is already renderable.
complete	Live web + Agent Builder + structured coerce finished (or were skipped).
error	Elasticsearch was down when the scan was loaded. Later stages record skipped / unavailable and keep going.

revision increments on every write, including stage timings and status patches.

Research pipeline

research/pipeline.py runs six stages, each in its own timeout / try-except:

Stage	What it does	Talks to
0 Load	Read the scan from peel-scans. Requires Elasticsearch.	Elasticsearch
1 Normalize	Join keys: RxNav approximate-term, NDC shape, imprint tokens. Best-effort.	RxNav
2 Deterministic	Exact lot / NDC / imprint-ladder / regulatory search. Writes a full report. Status → partial.	Elasticsearch
3 Web	Build a tiny query set, search + scrape, index hits into peel-web-pages.	Firecrawl → Elasticsearch
4 Agent	Elastic Agent Builder converse() with eight ES|QL tools over the same indices.	Kibana → Elasticsearch
5 Coerce	OpenAI structured output folds agent text + evidence pack into ResearchReport.	OpenAI

If Firecrawl, Agent Builder, or OpenAI is missing or errors, the stage records skipped / unavailable and the stage-2 report stands.

Field-level contracts, mappings, and retrieval math live in backend/README.md.

Backend

The backend is a FastAPI app (backend/src/backend) that owns vision, the scan store, retrieval, the research agent, concern reports, and the Deepgram handoff. Elasticsearch is the database.

Runpod

The API is meant to run as a long-lived process on Runpod. backend/scripts/runpod-start.sh is the container entrypoint:

1. Installs uv under /workspace when missing.
2. uv sync --locked --no-dev --python 3.13.
3. uvicorn backend.app:app --host 0.0.0.0 --port 8000.

Locally the same app is uv run backend (reload on 127.0.0.1:8000). Secrets come from a repo-root .env, then backend/.env (later wins). On boot, app.py calls ensure_indices() so the five strict Elasticsearch mappings exist before the first POST /scans. If the cluster is unreachable at startup, the process logs a warning and later requests return 503.

The physical instrument (Seeed XIAO ESP32-S3 + ESP32-S3-BOX-3 display) streams JSON over USB to mobile. The app sends timestamped optical readings with the scan. Research and voice receive bounded samples and channel statistics, separately from drug identity. The old mock POST /pill endpoint has been removed.

Elasticsearch

Everything Peel remembers lives on one Elastic Cloud Serverless “VectorDB” project (Elastic 9.6). Vector search goes through semantic_text fields backed by Elastic Inference (.jina-embeddings-v5-text-small).

Mappings are dynamic: "strict". An unmapped field is rejected at index time, so knowledge/fields.py is the single source of truth for names across seed adapters, search, and Agent Builder tools.

Five indices:

Index	Role	Search
peel-regulatory	Recalls and alerts: FDA, WHO, Health Canada, MHRA, NAFDAC.	Yes — body_semantic (title + reason + a short product slice). Lot numbers stay on keyword fields.
peel-pills	NLM Pillbox imprint archive (~84k, frozen Jan 2021).	Keyword lookups
peel-ndc	openFDA NDC directory (~138k). Brand, generic, labeler, listing status.	Keyword lookups
peel-web-pages	Pages Firecrawl (or the agent) fetched. Grows on every live scan.	Yes — page_semantic.
peel-scans	One document per check: bottle, imprint, hardware, report, evidence, stage timings.	Keyword / stored

Two retrieval modes:

• Exact lookups (recalls_by_lot, recalls_by_ndc, ndc_directory, the pill ladder) are constant_score term queries. They keep raw scores and are unioned with hybrid hits, so an old exact lot match still appears.
• Hybrid + recency decay (search_regulatory, search_web) is an Elasticsearch linear retriever. BM25 (weight 1.0) and semantic (weight 1.2) each get a Gaussian decay, then minmax-normalized and summed. The filter is pushed into every leg, so the vector search runs on an already-narrowed candidate set.

Decay floors: a regulatory record's score floor is 35% (30-day offset, 730-day half-life). A web page uses a 7-day half-life and a 0.20 floor. recency_date on a web page is published_at or last_changed_at. Re-fetching unchanged HTML leaves that date in place.

Lot strings collide (same code, different manufacturer; extraction junk like "MG30"). After a lot term hit, the backend corroborates against NDC and drug name. Only exact_lot / all_lots_product can become verdict recall_match. A lot that matches a different product, or an NDC that only appears because openFDA listed every sibling strength, stays a caution.

Imprint identification is a ladder: exact imprint first, then shape family as a hard filter, then shape as a boost, then fuzzy text. Color and size re-rank among documents that already matched an imprint tier.

Elastic Agent Builder

Stage 4 is a Kibana Agent Builder agent (peel-research-agent) with eight ES|QL tools compiled against the real mappings:

Tool	Does
peel.recalls_by_lot	Exact batch match.
peel.recalls_by_ndc	Product-line recall lookup by 9-digit NDC.
peel.regulatory_search_text	Keyword search with metadata filters + recency.
peel.regulatory_search_semantic	Unfiltered vector search, score floor 0.70.
peel.pill_lookup	Imprint as-read against peel-pills.
peel.ndc_lookup	Registered identity for an NDC.
peel.web_evidence_search	Already-fetched pages, 7-day decay.
peel.prior_scans	Counts of earlier Peel scans for the same lot/NDC.

The agent is registered on the first research request. POST /scans can succeed while Kibana is down. Specs are hashed onto the agent; converse() re-registers if another process overwrote them.

The evidence pack from stages 2–3 is passed in as already-executed tool results. Follow-up tools run for remaining gaps. On a conclusive lot hit that is one LLM call and ~25 s; ambiguous scans still take 40–60 s if follow-up tools run. The agent’s prose is an intermediate. Stage 5 (gpt-4o structured output) is what the client stores as research.

Kibana URL, if unset, is derived from ELASTICSEARCH_URL by replacing .es. with .kb..

Firecrawl

Stage 3 is the only place the backend spends Firecrawl credits. peel-seed fetches regulator bulk files and HTML over anonymous HTTP.

Per scan, at the defaults:

Limit	Default
Searches	2
Pages scraped per search	3
Credits per search	2 + pages
Per-scan cap	10 (2 × (2 + 3))
Process-wide daily cap	150

Queries are planned against that budget before anything is called. Planned searches run concurrently (asyncio.gather) inside a 75 s stage timeout. Social/video/forum domains are excluded (-site: plus a post-fetch drop).

Every fetched page is upserted into peel-web-pages by URL hash. Next time the same query is still inside its TTL (regulator 24 h, news 6 h, reference 7 d, other 48 h) and already has ≥2 pages, the scan spends 0 credits and just appends its scan_id. The corpus gets smarter the more it is used.

There is an optional Kibana Firecrawl connector (AGENT_BUILDER_FIRECRAWL_CONNECTOR_ID) that lets the agent fetch pages itself, uncapped. Pages it pulls are still harvested back into peel-web-pages. Treat that flag as demo-only.

OpenAI, Deepgram, reports

• Vision — POST /photo-identification/bottle and /imprint send the image to GPT-4o with prompts that extract structured fields and drop personal identifiers. The scan stores a SHA-256 fingerprint in photos[].
• Coerce — stage 5 is responses.parse into ResearchReport. Citations are rebuilt from the evidence pack; the model may pick which stored id to cite.
• Deepgram — POST /deepgram/session mints Voice Agent settings from a partial/complete scan. The agent receives scan_context as a string (ElevenLabs-style dynamic variable).
• Reports — POST /scans/{id}/reports stores purchase date, place, and seller. The voice agent can draft; only the app’s Submit button writes.

Seed corpus

uv run peel-seed seed --sources all

Source	Index	Rough size
openFDA enforcement	peel-regulatory	~18k
Health Canada	peel-regulatory	~4k
MHRA	peel-regulatory	~600
NAFDAC	peel-regulatory	~400
WHO alerts	peel-regulatory	~80
NLM Pillbox	peel-pills	~84k
openFDA NDC	peel-ndc	~138k

~3 minutes once raw files are cached in backend/data/ (gitignored). Idempotent: deterministic _ids overwrite. Anonymous HTTP only.

Getting started

Prerequisites: Python 3.13, uv, OpenAI key, Elastic Cloud endpoint + API key. Optional: Firecrawl, Deepgram.

git clone https://github.com/viktorinkov/HackMIT-2026.git
cd HackMIT-2026/backend
uv sync
cp .env.example .env

OPENAI_API_KEY=sk-...
ELASTICSEARCH_URL=https://....es....elastic.cloud
ELASTICSEARCH_API_KEY=...
FIRECRAWL_API_KEY=     # blank skips live web
DEEPGRAM_API_KEY=      # blank skips voice session minting

uv run peel-seed seed --sources all
uv run backend                 # http://127.0.0.1:8000  — OpenAPI at /docs

Hardware firmware, debug app, and simulator: hardware/README.md.

cd backend
uv run pytest
uv run python scripts/smoke.py          # read-only against the seeded cluster
uv run python scripts/smoke.py --e2e    # one full scan (Firecrawl + OpenAI)

HTTP API

Interactive docs: http://127.0.0.1:8000/docs.

Method	Path	Role in the architecture
POST	/photo-identification/bottle	Vision → bottle observation
POST	/photo-identification/imprint	Vision → imprint observation
POST	/scans	Create scan, start pipeline (202)
GET	/scans/{id}	Poll envelope (pending / partial / complete)
GET	/scans/{id}/context	scan_context for the voice agent (?as_string=true)
POST	/scans/{id}/research	Re-run pipeline ({"force": true} cancels in-flight)
GET	/scans?device_id=	History by device, lot, or NDC
POST	/scans/{id}/reports	Concern report
POST	/deepgram/session	Mint Deepgram settings from a ready scan
GET	/knowledge/lot/{lot}	Direct lot lookup
GET	/knowledge/ndc/{ndc}	NDC directory + related recalls
GET	/knowledge/pill	Imprint ladder
GET	/knowledge/search	Hybrid regulatory or web search
GET	/knowledge/stats	Index counts
GET	/health	Liveness

Peel Voice Agent

After Results, Talk to Peel opens a Deepgram Voice Agent session for that scan. One WebSocket runs STT, the LLM, and TTS. The app never ships the API key: POST /deepgram/session mints a temporary token. You can interrupt the greeting; keyterms come from this scan; the latency chip is Deepgram’s total_latency; Flux TTS falls back to Aura-2 if needed. A HIPAA BAA is Enterprise-only.

The longer judge-facing write-up is docs/deepgram/WHY-DEEPGRAM.md.

Project layout

HackMIT-2026/
├── backend/                 FastAPI app on Runpod
│   ├── src/backend/         vision, scans, research, knowledge, reports, Deepgram
│   ├── scripts/             smoke tests, runpod-start.sh
│   └── README.md            mappings, retrieval, Agent Builder, Firecrawl budget
├── hardware/                XIAO firmware, BOX-3 face, debug Flutter app, simulator
├── assets/                  README images and media placeholders
├── photos-for-testing/      sample bottle and imprint photos
└── LICENSE

License

MIT. See LICENSE.

Seeded records keep their upstream licences (openFDA/CC0, WHO CC BY-NC-SA 3.0 IGO, Health Canada and MHRA Open Government Licence, NAFDAC summarise-and-link, Pillbox/RxNav US public domain). Those terms travel with the indexed documents.
