Clip Architect

Turn a topic into a finished short video — on your own machine, with your own keys.

Install from the Microsoft Store — one click, no build steps, updates handled by Windows.

diflowrin.com — project page, downloads and release notes.

---

Clip Architect is a desktop build of MoneyPrinterTurbo: give it a subject, and an LLM writes the script and the search keywords, stock footage or your own files supply the picture, a text-to-speech engine speaks the narration, and FFmpeg cuts the clips to the voice track, burns in subtitles, mixes background music and writes an MP4 sized for TikTok, Reels or Shorts.

Upstream is a Python web app (FastAPI + a Streamlit UI) that you start from a terminal and use in a browser. This repackages it as a single Windows application: a Tauri shell owns the window and the process lifecycle, a React frontend replaces Streamlit, and the Python backend runs as a private local service that starts and stops with the app.

Local-first. Everything runs on your machine. Nothing is uploaded anywhere except to the provider you chose, with the key you supplied. No account, no subscription, no cloud render queue.

See it

Clip Architect Desktop — the app itself.	Bass Through the Cosmos — a short made with it.

Features

• Script and keywords from any of 23 LLM providers — OpenAI, Anthropic Claude, Google Gemini, DeepSeek, Qwen, Moonshot/Kimi, xAI Grok, Groq, OpenRouter, Ollama and more. Adding one is a registry entry, not a code path.
• Footage from Pexels, Pixabay, or your own local video files.
• Narration via Edge TTS (free, no account), Azure Speech, or ElevenLabs. Voices are listed per engine, and the app says up front when a key is missing instead of failing silently at the render stage.
• Burned-in subtitles with a choice of bundled font, size, position, colour and outline, previewed before you render.
• Background music from the 8 bundled tracks or your own uploads.
• Review before render — an optional pass that downloads the clips and lets you reorder, remove or replace any of them before spending the minutes and the provider quota. A clip can be replaced with a file of your own or with a fresh one fetched by keyword; asking again offers a clip you have not been shown yet, falling through to another stock provider when one runs dry. Finished tasks can be reopened for another pass.
• Voice-over first — record and listen to the narration on its own, with its duration, before committing to a full render.
• Saved projects and a library of past renders, plus a reusable cache of downloaded clips shared across tasks.
• Output at 9:16, 16:9 or 1:1.

Every product-facing string is in English.

Requirements

• Windows 10 1809 or newer, with the WebView2 runtime
• Rust with the MSVC toolchain
• Node.js 20+
• uv (the backend pins Python 3.11)

FFmpeg is bundled (an LGPL build), so end users do not need to install it. It is ~110 MB and therefore not in version control — fetch it once with npm run ffmpeg:fetch.

It must stay an LGPL build. See Third-party licenses for why: a GPL build carries libx264, and distributing an H.264 encoder brings patent licensing that the app avoids by calling the encoder built into Windows.

Development

# once
npm install
npm run backend:sync     # uv sync --python 3.11 in backend/
npm run ffmpeg:fetch     # LGPL FFmpeg -> backend/resource/bin/

# run
npm run tauri:dev

In debug builds the Rust shell runs backend/sidecar.py directly from the uv virtualenv, so Python changes only need an app restart — no re-freezing. It still passes MPT_ROOT_DIR and MPT_RESOURCE_DIR, so the dev and release layouts behave identically.

Checks

npm run backend:test     # pytest
npm run build            # tsc -b + vite build (catches more than tsc --noEmit)
npm run lint             # oxlint
cd src-tauri && cargo check && cargo test

tsc --noEmit does not apply the project tsconfig — use the npm script. cargo check alone only compiles the debug_assertions branch of the backend command; add --release to cover the release-only path.

Architecture

┌─────────────────────────────────────────────────┐
│ ClipArchitect.exe          (Tauri / Rust)       │
│                                                 │
│  ├── WebView2 ── React + TypeScript frontend    │
│  │                    │                         │
│  │                    │ HTTP to 127.0.0.1:<port>│
│  │                    ▼                         │
│  └── supervises ── ca-desktop-backend.exe       │
│                    (PyInstaller: FastAPI +      │
│                     moviepy + ffmpeg + TTS)     │
└─────────────────────────────────────────────────┘

The Rust shell (src-tauri/src/backend.rs) reserves a free loopback port, starts the backend with that port, waits for it to accept connections, and kills it on exit. The frontend never assumes a fixed port: it receives the base URL from the shell over the backend://status event. The child is assigned to a Windows Job Object with KILL_ON_JOB_CLOSE, so a crash or a Task Manager kill cannot leave the backend rendering in the background.

First startup is slow — around 70 s cold while Defender scans the ~290 MB bundle, ~20 s warm — so the startup timeout is deliberately generous.

Repository layout

Path	What it is
src/	React frontend: three views — Generate, Library, Settings
src-tauri/	Rust shell: window, process supervision, capabilities
backend/app/	Vendored MoneyPrinterTurbo, patched where noted in LICENSES-third-party.md
backend/sidecar.py	Entry point when run as a Tauri sidecar (replaces upstream main.py)
backend/test/	Upstream suite, minus tests for components not shipped
packaging/	Upstream tests and assets held out of the shipped build
scripts/	FFmpeg fetch, and the resource-dir guard both tauri commands need

Where files live

Upstream derives every path from __file__, which breaks the moment the code runs from a read-only install directory or a PyInstaller temp folder. The backend resolves two directories from the environment (backend/app/paths.py):

Variable	Contents	Writable
MPT_ROOT_DIR	config.toml, storage/ (renders, downloaded footage, uploads)	yes — per-user app data
MPT_RESOURCE_DIR	fonts/, songs/, public/, bin/ffmpeg.exe	no — inside the install

Both fall back to the source-tree layout when unset, so a plain python sidecar.py still behaves like upstream.

This split is what makes a Microsoft Store (MSIX) build possible: MSIX installs under C:\Program Files\WindowsApps, which the app cannot write to.

Release build

The Python backend must be frozen first; the Tauri build only bundles what is already on disk.

npm run backend:freeze   # PyInstaller -> backend/dist/backend/
npm run tauri:build      # -> src-tauri/target/release/

Skipping the freeze ships stale Python — the frozen bundle goes out of date silently, because dev builds never touch it.

sidecar.spec produces a one-directory bundle on purpose. A one-file build re-extracts several hundred megabytes into %TEMP% on every launch, which is slow and trips antivirus heuristics; MSIX also expects a static, pre-laid-out payload.

A release bumps two literals that no check ties together: version in src-tauri/tauri.conf.json and the version in the sidebar (src/App.tsx).

Backend API

The frontend talks to a plain HTTP API under /api/v1; /docs on the backend's port serves the generated OpenAPI UI during development.

Method	Path	Purpose
POST	/videos	Queue a full render, returns task_id
POST	/materials	Prepare materials and stop for review
POST	/audio	Record the narration only
POST	/subtitle	Generate subtitles only
POST	/tasks/{id}/render	Render a reviewed task from its approved clips
POST	/tasks/{id}/reopen	Reopen a finished task's clips for another pass
POST	/tasks/{id}/material_search	Fetch one stock clip by keyword, to swap into a reviewed list
GET	/tasks	Paginated task list
GET/DELETE	/tasks/{id}	Task state and progress / delete it and its output
POST	/scripts	Generate a script with the configured LLM
POST	/terms	Generate stock footage keywords
POST	/social-metadata	Generate a title, description and hashtags
GET/POST	/musics	List / upload background music
GET/POST	/video_materials	List / upload local footage
GET/DELETE	/downloaded_materials	The shared clip cache / delete one clip
GET	/material_preview/{path}, /material_thumbnail/{path}	Stream a clip, or a still frame generated on demand
GET/POST/PUT/DELETE	/projects, /projects/{id}	Saved projects
GET/PUT	/settings	Read and persist config.toml
GET	/metadata/{fonts,voices,llm-providers,llm-models}	Form options
GET	/ping	Health check the shell waits on

The settings, metadata, projects and review routes are additions. Upstream had no need for them because Streamlit ran inside the backend process and edited configuration in memory; a separate frontend cannot.

Configuration

Everything is stored in config.toml in the app data folder, editable from the Settings tab. Nothing ships with credentials — the app is inert until you supply at least an LLM provider key and, unless rendering from local files, a Pexels or Pixabay key.

The credential-free path is local footage + Edge TTS, which needs no account at all. That path matters twice over: it is the honest first run for a new user, and it is what a Microsoft Store certification reviewer — testing on a clean install with no accounts — needs in order to see the app do anything.

Known limitations

• Windows only. The shell, the MSIX packaging and the h264_mf encoder are all Windows-specific.
• No CJK subtitle font ships. Latin, Vietnamese, Cyrillic, Greek and Thai are covered; Chinese, Japanese and Korean render as blank glyphs rather than failing.
• H.264 is Constrained Baseline, because it is encoded through Windows Media Foundation rather than a bundled encoder. Files are larger than libx264 would produce. This is a patent decision, not an oversight; HEVC is never emitted.
• Several upstream integrations are vendored but not surfaced in the UI — LoomLoom video generation, Sonilo and ElevenLabs music generation, TwelveLabs reranking, social cross-posting. They live in backend/app/services/.

License

Clip Architect is dual-licensed.

GPL-3.0 — for the community

The default, and the licence in LICENSE. Free of charge, for everyone. Use it, study it, modify it, and make videos with it — including videos you sell. What GPL-3.0 asks in return is that if you distribute the software or anything derived from it, you do so under GPL-3.0 too, with source.

Commercial license — for proprietary use

For what the GPL does not permit: embedding Clip Architect in a closed-source product, redistributing it without publishing source, or shipping it under your own brand. Granted by written agreement with the author, with optional technical support and SLA. See COMMERCIAL-LICENSE.md.

Either way, the videos are yours

Neither licence claims any right over the material Clip Architect produces. What you render is yours to publish, sell or monetise. The same goes for what you put in — your footage and your scripts stay yours. Only the terms of the providers you configure, and the licences of what the app bundles, apply on top.

---

The upstream MoneyPrinterTurbo code is MIT and keeps its notice (LICENSE-MoneyPrinterTurbo); MIT is one-way compatible with the GPL, so the combined work ships under GPL-3.0. Nothing bundled forces that choice — the FFmpeg build is LGPL — so it is a preference, not an obligation inherited from a dependency. That is also what makes the second licence possible: nothing shipped here carries a copyleft obligation the author cannot waive.

LICENSES-third-party.md covers the bundled fonts, music, FFmpeg and codec selection, and documents what was removed from upstream and why. Read it before shipping — several of those removals were licensing blockers, not cleanups.

licenses/ is the copy that ships. The folder is bundled as an application resource, so an installed Clip Architect carries the GPL-3.0, MIT, LGPL, OFL and Python dependency texts on disk beside the executable, where several of those licences require them to be. LICENSES-third-party.md holds the reasoning; licenses/THIRD-PARTY-NOTICES.md is the notice a user or a certification reviewer actually reads.

Credits

Built on MoneyPrinterTurbo by Harry. Shell by Tauri. Media by FFmpeg (LGPL build) and MoviePy.

Thanks to the footage providers

Clip Architect does not host a single frame of stock video. Everything it cuts comes from the two libraries below, fetched at render time with your own free API key, and both are thanked here because the app would have nothing to show without them:

• Pexels — free stock video, no attribution required, under the Pexels License. Get a key at pexels.com/api.
• Pixabay — free stock video under the Pixabay Content License. Get a key at pixabay.com/api/docs.

Both licences allow commercial use of the finished video, and neither requires crediting the clip in it — but the terms are theirs to change, and they are worth reading before you publish at scale. Crediting a creator you liked costs nothing and is the reason the libraries stay free.

The local footage + Edge TTS path needs no stock provider and no account at all.
