Summary

Seat automatically wrapped PowerPoint paragraphs using the paragraph-end font
only on the final physical line. The startup fixture's first text line and
bullet move from 142pt to 143pt (native: 143.04pt), while its final line keeps
the mark's font seat. Typst retains responsibility for shaping, wrapping and
layout height; completed-frame adjustments keep links and underlines with
their text. Centered and bottom-anchored stories use their local origin.

Native one-factor width and mark-font probes isolate the cause: changing only
the width makes the first baseline 143.04pt when wrapped or 142.08pt when
unwrapped; changing only the end-mark face moves the final wrapped line.
Explicit hard breaks retain their existing line-stack path. Scripted runs
retain their existing behavior until logical lines can be distinguished from
superscript/subscript baselines.

Related issue

Related: #1177. Remaining independent defects: #1581, #1582, #1583, #1584.

Testing

  • cargo test --locked --workspace --no-fail-fast: passed (3484 tests; 15 ignored).
  • cargo clippy --locked --workspace --all-targets -- -D warnings: passed.
  • cargo fmt --all -- --check and git diff --check: passed.
  • RED/GREEN regressions for final-line mark seating, centered Korean paragraphs,
    all three wrapped list markers, and link/underline positions. An embedded-font
    regression checks the same behavior without depending on installed Office fonts.
  • Fresh native PowerPoint exports and all four comparison axes on eleven pages.
    Searchable text matches (1,608 normalized codepoints; identical codepoint census).

Visual impact

  • No rendered PDF change
  • Rendered PDF change or visual evidence added

Visual audit

Visual comparison

Each image contains the eleven full pages in collection order.

GT Before After
GT Before After

Required inspection

  • Rendered all evidence at 150 DPI or higher
  • Stored progressive JPEG quality 86 assets with metadata stripped
  • Used Codex/Claude vision to inspect the full GT/output pages, diff, and matched crops
  • Inspected matched region crops at full resolution
  • Ran compare_layout.py --audit --fine-shift PT and dispositioned every fine/large text-instance shift, rectangle geometry deviation, painted-text visibility mismatch, and visible-fill occlusion
  • Ran compare_render.py --cluster-report PATH --strict-clusters and dispositioned every material 5% fuzz diff cluster by explicit ID
  • Inventoried hairlines and border dash styles
  • Inventoried font weight, italic, and underline emphasis

Deviation audit

Check Result
Page count/order Matches GT: all eleven pages in the documented fixture order.
Element presence Matches GT: text, markers, shapes and pictures remain present.
Position/size Remaining: #1581, #1582, #1583, #1584; advance-grid, cross-space kerning, story-origin rounding and continuation-line rounding respectively.
Rotation/flip Matches GT.
Fill Matches GT: covers, cards, chart fills and Korean panel.
Stroke/border Matches GT: thin axes, ticks, legend outlines and bar edges remain present.
Shape outline geometry Matches GT.
Text content Matches GT: normalized searchable text and codepoint census agree.
Font family/weight/style Matches GT: same title/body weights and Korean emphasis in full-scale crops.
Text color Matches GT.
Alignment Fixed: first wrapped line and bullet use the nonfinal font seat.
Line/paragraph spacing Remaining: #1583, #1584; fractional origin and continuation-line rounding.
Clipping/overflow Matches GT on the original eleven-page fix collection.

Checklist

  • Commits include a Signed-off-by line
  • PR scope contains one root cause
  • Remaining converter or harness deviations each reference an open issue

Signed-off-by: Yonghye Kwon <developer.0hye@gmail.com>
