NASA API Implementation

📌 Project Overview

Welcome to the NASA API Implementation project! This full-stack web application utilizes NASA's public APIs to provide users with captivating Astronomy Picture Of The Day (APOD) and Mars Rover Photos. Developed as part of a 30-day development internship program, this project demonstrates the integration of various modern technologies to create a robust, secure, and user-friendly application.

Discover breathtaking astronomical imagery and fascinating Mars exploration photos through an intuitive interface, complete with administrative features for data management and a comprehensive API for developers.

✨ Features

🌠 Astronomy Picture Of The Day (APOD)

View the current APOD with detailed explanations
Browse previously saved APODs
Admin functionality to manage APOD entries (CRUD operations)

🔭 Mars Rover Photos

Select from three different Mars rovers:
- Curiosity
- Opportunity
- Spirit
Choose from multiple cameras on each rover:
- FHAZ (Front Hazard Avoidance Camera)
- RHAZ (Rear Hazard Avoidance Camera)
- MAST (Mast Camera)
- CHEMCAM (Chemistry and Camera Complex)
- MAHLI (Mars Hand Lens Imager)
- MARDI (Mars Descent Imager)
- NAVCAM (Navigation Camera)
- PANCAM (Panoramic Camera)
- MINITES (Miniature Thermal Emission Spectrometer)
Filter photos by Earth date

🔒 Security Features

Custom login page with JWT authentication
Role-based access control (EMPLOYEE and ADMIN roles)
OAuth2 resource server integration
Protected API endpoints

📊 Developer Tools

Comprehensive Swagger documentation
RESTful API endpoints for APOD and Mars Rover data
Detailed error handling

🛠️ Technology Stack

Backend

Spring Boot 3 and Spring Framework 6 for application framework
Spring MVC for web layer
Spring Data JPA for data access
Spring Security with JWT for authentication and authorization
MySQL for database storage
Swagger/OpenAPI for API documentation

Frontend

Thymeleaf for server-side templating
Bootstrap for responsive UI components
HTML5/CSS3 for markup and styling

Deployment & Tools

Docker for containerization
AWS Elastic Beanstalk for cloud deployment
Maven for dependency management

🏗️ Project Architecture

The application follows a layered architecture:

Application Structure

├── com.openapi.nasa
│   ├── NasaApiApplication.java (Main application class)
│   ├── daorepo (Data Access Layer)
│   │   └── NasaRepository.java
│   ├── entity (Entity Classes)
│   │   └── NasaApod.java
│   ├── exceptionHandler (Error Handling)
│   │   ├── NasaErrorResponse.java
│   │   ├── NasaGlobalExceptionHandler.java
│   │   └── NasaNotFoundException.java
│   ├── model (Model Classes)
│   │   ├── MarsRover.java
│   │   ├── MarsRoverCamera.java
│   │   ├── MarsRoverPhoto.java
│   │   └── RoverPhotoRequests.java
│   ├── mvcController (Web Controllers)
│   │   ├── LoginController.java
│   │   └── NasaMvcController.java
│   ├── response (Response Objects)
│   │   └── MarsRoverPhotosResponse.java
│   ├── rest (REST Controllers)
│   │   └── NasaApiController.java
│   ├── security (Security Configuration)
│   │   ├── JwtAuthenticationResource.java
│   │   ├── OpenApiConfig.java
│   │   └── SecurityConfiguration.java
│   └── service (Service Layer)
│       ├── NasaApiService.java
│       └── NasaApiServiceImpl.java

Frontend Templates

├── resources
│   └── templates
│       └── nasa
│           ├── access-denied.html
│           ├── apod.html
│           ├── custom-login.html
│           ├── custom-login-2.html
│           ├── home-page.html
│           ├── index.html
│           ├── list-apods.html
│           ├── result.html
│           └── update-apod-form.html

📊 Business Flow Diagram

flowchart TD
    START([User Accesses Application]) --> LOGIN{Login Required?}
    LOGIN -->|Yes| AUTH[Authentication Process]
    LOGIN -->|No| GUEST[Limited Guest Access]

    AUTH -->|Success| ROLE{Verify Role}
    AUTH -->|Failure| LOGIN_ERROR[Show Error Message]

    ROLE -->|EMPLOYEE| HOME[Home Page]
    ROLE -->|ADMIN| HOME

    HOME --> APOD_VIEW[View APOD]
    APOD_VIEW --> NASA_APOD[Fetch from NASA APOD API]

    HOME --> ROVER_SELECT[Mars Rover Selection]
    ROVER_SELECT --> SELECT_PARAMS[Select Parameters]
    SELECT_PARAMS --> FETCH_PHOTOS[Fetch Mars Rover Photos]
    FETCH_PHOTOS --> DISPLAY_PHOTOS[Display Rover Photos]

    APOD_VIEW -->|Admin Only| MANAGE_APOD{Manage APOD Options}
    MANAGE_APOD -->|Add/Update/Delete| DB_OPS[(Database Operations)]

🚀 Getting Started

Prerequisites

Java 17 or higher
Maven 3.6+
MySQL 8.0+
NASA API Key (register at https://api.nasa.gov/)

Installation Steps

Clone the repository

git clone https://github.com/yourusername/nasa-api-implementation.git
cd nasa-api-implementation

Configure application properties

Create application.properties in src/main/resources
Add the following configurations:

# Database Configuration
spring.datasource.url=jdbc:mysql://localhost:3306/nasa_db
spring.datasource.username=your_username
spring.datasource.password=your_password
spring.jpa.hibernate.ddl-auto=update

# NASA API Configuration
nasa.api.key=your_nasa_api_key

# Server Configuration
server.port=5000

Set up database

Create a MySQL database named nasa_db
Create tables for user authentication:

CREATE TABLE nasa_members (
  user_id VARCHAR(50) NOT NULL,
  pw VARCHAR(100) NOT NULL,
  active BOOLEAN NOT NULL,
  PRIMARY KEY (user_id)
);

CREATE TABLE nasa_roles (
  user_id VARCHAR(50) NOT NULL,
  role VARCHAR(50) NOT NULL,
  PRIMARY KEY (user_id, role),
  FOREIGN KEY (user_id) REFERENCES nasa_members(user_id)
);

-- Add an admin user
INSERT INTO nasa_members (user_id, pw, active)
VALUES ('admin', '{bcrypt}$2a$10$dXJ3SW6G7P50lGmMkkmwe.20cQQubK3.HZWzG3YB1tlRy.fqvM/BG', true);

INSERT INTO nasa_roles (user_id, role)
VALUES ('admin', 'ROLE_ADMIN');
INSERT INTO nasa_roles (user_id, role)
VALUES ('admin', 'ROLE_EMPLOYEE');

-- Add a regular user
INSERT INTO nasa_members (user_id, pw, active)
VALUES ('user', '{bcrypt}$2a$10$dXJ3SW6G7P50lGmMkkmwe.20cQQubK3.HZWzG3YB1tlRy.fqvM/BG', true);

INSERT INTO nasa_roles (user_id, role)
VALUES ('user', 'ROLE_EMPLOYEE');

Note: The encrypted password is 'test123'

Build the application
```
mvn clean install
```
Run the application
```
mvn spring-boot:run
```
Access the application
- Web interface: http://localhost:5000/nasa/home-page
- Swagger documentation: http://localhost:5000/swaggerdoc.html

🌐 API Endpoints

APOD Endpoints

GET /api/apod - Get current APOD
GET /api/apods - Get all stored APODs
GET /api/save-apod - Save current APOD to database
GET /api/apod/{apodId} - Get APOD by ID
PUT /api/apod/{apodId} - Update APOD
DELETE /api/apod/{apodId} - Delete APOD

Mars Rover Endpoints

GET /api/rover/{roverName}/{earthDate}/{roverCamera} - Get Mars Rover photos

Authentication Endpoints

POST /authenticate - Get JWT token
GET /get-token - Alternative method to get JWT token

👥 Roles and Access

EMPLOYEE Role:
- View APOD
- Access Mars Rover photos
- Access basic API endpoints
ADMIN Role:
- All EMPLOYEE permissions
- Manage APOD entries (create, update, delete)
- Access administrative endpoints

📅 Development Timeline (30-Day Internship)

Week 1: Project Setup and Basic Implementation

Day 1-2: Project structure setup and requirements analysis
Day 3-4: Entity design and repository implementation
Day 5-7: NASA API integration for APOD and Mars Rover

Week 2: Core Functionality Implementation

Day 8-10: MVC controller implementation
Day 11-12: Thymeleaf template development
Day 13-14: REST API implementation

Week 3: Security and Advanced Features

Day 15-17: Spring Security configuration with JWT
Day 18-19: Role-based access control implementation
Day 20-21: Exception handling and validation

Week 4: Polish and Deployment

Day 22-24: UI enhancement and responsive design
Day 25-26: Swagger documentation and API testing
Day 27-28: Docker containerization and deployment preparation
Day 29-30: Final testing and deployment to AWS Elastic Beanstalk

🔍 Using the Mars Rover API

The Mars Rover endpoint allows for precise filtering of Mars photos:

/api/rover/{roverName}/{earthDate}/{roverCamera}

Examples:

/api/rover/curiosity/2015-06-03/fhaz - Get photos from Curiosity's front hazard camera from June 3, 2015
/api/rover/opportunity/2018-01-10/pancam - Get photos from Opportunity's panoramic camera from January 10, 2018
/api/rover/spirit/2010-02-15/navcam - Get photos from Spirit's navigation camera from February 15, 2010

📝 Notes for API Users

If you access /swaggerdoc.html directly without logging in, you can use the bearer token (JWT Authentication) for authorization. To get a JWT Bearer token, use the endpoint: /get-token (e.g., http://localhost:5000/get-token).

Alternatively, you can use normal credentials to access http://localhost:5000/swaggerdoc.html.

📷 Screenshots

Home Page

APOD View

Mars Rover Photos

Admin Panel

🤝 Contributing

This project was developed as part of a 30-day internship program. While it's primarily for educational purposes, contributions are welcome. Please feel free to fork the repository, make improvements, and submit pull requests.

🔗 Contact & Support

For any questions or support regarding this project, please contact:

Email: varungrvv@gmail.com

📜 License

This project is licensed under the MIT License - see the LICENSE file for details.

🙏 Acknowledgements

NASA Open APIs for providing access to incredible space data
Spring Framework for the robust application framework
All the interns who contributed to the development of this project

Developed with ❤️ during the 30-day Development Internship Program.
